Airpress 369007 APS 7.5 CombiDry X Screw Compressor 230 Volt
Special features
- The new APS COMBI DRY X models from Airpress combine quality with an attractive price.
- These direct-drive screw compressors with a power output of 5.5 KW are supplied as CombiDry models.
- Direct drive of the screw block means less maintenance and a compact design.
- Due to the large screw block, the rotational speed is low and the machine produces little noise.
- The fan is temperature-switched, allowing the machine to reach operating temperature faster.
- The multifunctional control panel is adjustable in multiple languages and allows the user to read and set multiple parameters.
- The machine can also be connected to a remote control.
Readable from the display
- Min. pressure / max. pressure
- Operating pressure
- Oil temperature
- Fan on/off temperature
- Maintenance interval
- Voltage on the phases
Technical data
- Power hp / kW 7.5 / 5.5
- Stages 1
- Capacity at 10 bar (l/min) 690
- Refrigerant Air
- Drive Direct
- Start Y-Ôêå
- Boiler capacity (l) 200
- Dryer voltage 230 V / 50 Hz / 1 Ph
- Length, Width, Height (mm) 1400 x 600 x 1430
- Weight (kg) 310
- Push button operation
- Display Mono
- Noise level dB(A) 63
- Air connection 3/4
Standard included
- Manual
