Fischer 50493 Aerated Concrete Plug GB 14 10 pieces
The Fischer Aerated Concrete Plug GB 14 is a special plug for a wide variety of fastenings in aerated concrete. Made of high-quality nylon, the GB plug is hammered in with a rotating motion after pre-drilling. The characteristic external ribs create a properly closing connection between the plug and the building material. The Fischer GB aerated concrete plug is ideal for fastening facade and roof structures, as well as railings made of aerated concrete.
Advantages
- The helical outer ribs cut a fit into the soft building material, thereby guaranteeing optimal pressure distribution and load-bearing capacity
- Can be installed with a hammer – no special tools are required, saving time and money during installation
- The GB can also be safely used outdoors (e.g. for facade mounting) when combined with the approved Fischer safety screw in A4.
Applications
- Aerated concrete with a concrete compressive strength of 2 to 4 N/mm²
- Wall or ceiling panels made of aerated concrete with a compressive strength of 3.3 to 4.4 N/mm²
Building materials
- The GB is suitable for through-hole mounting
- The helical outer ribs guarantee a secure fit between the building material and the plug
- The required screw length is determined based on: Plug length + thickness of the attached part + 1 x screw diameter
- Use rotary drilling to create the borehole
- Can be used in unplastered aerated concrete
Technical data
- Borehole diameter: 14 mm
- Min. borehole depth: 90 mm
- Plug length = min. anchoring depth: 75 mm
- Fischer Security Screw: 10 mm
- Content: 10
