Fischer 562205 DuoXpand construction plug 10 x 80 T countersunk head
Special features
- Thanks to the clever combination of material and design, the plug grips firmly in all substrates and is therefore universally applicable
- The expansion section with 2 anchoring depths allows for flexible use in all substrates
- Approved for multiple fastening of non-load-bearing systems in concrete, masonry, and aerated concrete
- The ribs prevent the plug from rotating during installation
- Pre-assembled screw with countersunk head
- Thanks to the clever combination of material and design, the plug grips firmly in all substrates, guaranteeing universal applicability
- The special lamella geometry carefully conforms to the respective building material. This prevents fractures in porous substrates and enables anchoring close to the edge. The high-quality nylon base guarantees a very strong fastening, while the flexible red lamellae ensure optimal distribution within the material. The European Technical Certification (ETA) for multiple anchorages of non-load-bearing systems guarantees safety in all substrates. The DuoXpand plug and pre-assembled safety screw are perfectly matched, which benefits installation speed. The DuoXpand is suitable for through-hole mounting. In solid substrates, the product offers the assurance of even load distribution. In perforated substrates, the lamella geometry adapts, after which a form-fitting is formed in the hollow space. The design of the plug transfers the load equally into the substrate, ensuring that even very porous bricks do not crack. The variant with a countersunk head is highly suitable for fastening wooden extensions to concrete and masonry. For metal attachments, we recommend using the variant with a hexagonal head.
Certified for:
- Concrete ≥ C12/15
- Solid brick
- Solid sand-lime brick
- Solid concrete blocks made of lightweight concrete and standard concrete
- Perforated brick
- Perforated sand-lime brick
- Hollow concrete blocks made of lightweight concrete
- Cellular concrete
Also suitable for:
- High-density natural stone
- Gypsum blocks
- Faccade and roof elements made of wood and metal
- Window frames
- Fences
- Wardrobes
- Kitchen cabinets
- Timber beams
- TV brackets
- Facade cladding
- Metal brackets
- Metal supports
- Cable trays
- Pipe runs
Technical data
- Drive: TX40
- Drill diameter: 10 [mm]
- Plug length: 80 [mm]
- Suitable for aerated concrete: Yes
- Suitable for perforated brick: Yes
- Suitable for fastening with cable tie: No
- Suitable for natural stone: Yes
- Suitable for wood screws: Yes
- Surface protection: Other
- Color: grey
- Material: Plastic
- Useful length at anchoring depth 50 mm: 30 [mm]
- Useful length at anchoring depth 70 mm: 10 [mm]
- Material / corrosion protection: Plastic
- Material quality: Nylon
Scope of delivery
- 10 x construction plug DuoXpand 10 x 80 T
