Fischer 78416 Aerated concrete anchor FTP M 8 metal 25 pieces
The metal aerated concrete anchor for metric bolts.
Special features
- The fischer Turbo aerated concrete anchor FTP M is a special plug for fastenings in aerated concrete.
- The metal plug is inserted into the drilled hole using the pre-insertion method with an Allen key.
- The spiral external thread cuts precisely into the building material.
- The fischer Turbo aerated concrete anchor FTP M is particularly suitable for securely fastening mirror cabinets, radiators, and TV consoles in aerated concrete.
Advantages
- The Allen bit allows the FTP M to be set without the need for a special mounting tool.
- This enables easy installation.
- The FTP M achieves even greater security Very high load-bearing capacity in aerated concrete.
- The spiral-shaped external thread locks itself into the aerated concrete with a form-fit.
- This allows it to be installed without the need to apply force.
- The special geometry enables virtually expansion-pressure-free anchoring.
- This allows for small edge and spacing distances and prevents gaps in plastered surfaces.
Characteristic properties
- No mounting aid required.
- High fastening forces due to precise connection in the building material.
- Comfortable installation: less effort required.
- Small edge and axial distances due to expansion-pressure-free anchoring
Applications
- Paintings Lamps Shelves Mirror cabinets Curtain rails Cable and pipe clamps Spacer-mounted structures Radiators TV consoles
Building materials
- Aerated concrete Gypsum blocks
Installation
- The FTP M is suitable for through-hole mounting.
- During installation, the aerated concrete anchor cuts into the aerated concrete to fit precisely.
- Suitable for metric screws M6.
- When mounting with an Allen key: The size of the Allen key corresponds to the diameter of the screw, i.e. install with Allen key size 6.
- When mounting using a cordless screwdriver, work with low torque and use the matching 6-point bit FTP EM.
Technical data
- Drill hole diameter d0 10 - (12) [mm]
- Min. drill hole depth h1 70 [mm]
- Plug length l 60 [mm]
- Metric screw MM 8
- Min. screw-in depth lE,min 20 [mm]
- Max. screw-in depth lE, max 25 [mm]
Supplied as standard
- 25 pieces
