Fluke 289/EUR Digital RMS multimeter with data logging and trend capture
Special features
- The Fluke 289 TRMS industrial multimeter with data logging function and TrendCapture includes all the advanced capabilities of a digital multimeter that you would expect from a Fluke instrument and more...
- The optional Fluke ir3000 FC Wireless connector ensures that the Fluke 289 is compatible with the Fluke Connect Mobile App.
- With the Fluke Connect™ ShareLive™ video call feature, you can consult on-site with your colleagues, management, or customers.
- Better communication, greater safety, and higher productivity for faster and more informed decision-making.
- Key features include
- Large ¼" VGA display up to 50,000 counts, with white backlight
- Multiple sets of measurement information can be displayed simultaneously.
- The logging function with TrendCapture is an indispensable tool for documenting the performance of your designs, processes, or systems: these are monitored independently while you work on other projects.
- The instrument displays measurement results as a single line, for detecting signal deviations over time, and can store 10,000 measurements.
- With the integrated TrendCapture function, you can view a graphical representation of captured measurements without a PC. (Software and interface cable optional.)
- Logging of multiple sessions or continuous logging of data for over 200 hours.
- This comes in handy when specifying the performance of a design or for independent monitoring.
- i-information key/internal help screens for measurement functions
- Unsure about a function? Go to that function and press the ''i'' key.
- LoZ Volts
- The low-impedance function for voltage measurements prevents incorrect readings due to phantom voltage
- This is also the recommended mode for testing for the absence or presence of (mains) voltage.
- Low-pass filter for accurate voltage and frequency measurements on variable-speed drives and other devices that cause electrical interference.
- 50-ohm range, useful for measuring the resistance of motor windings and comparing differences therein, and for measuring low resistance values or other contact resistance
- Two connections for 50-ohm range with a resolution of 1 milliohm and a source current of 10 mA.
- You can save and name readings on the spot, and recall them later
- Real-time clock - for automatic time marking of saved values measured values
- Meter that can be upgraded and expanded on-site, allowing you to keep up with developments as new capabilities are added
- Event and trend recording – particularly useful for locating intermittent problems or analyzing load profiles.
- Multilingual interface
- Softkeys, scroll keys and easy navigation, access to secondary functions
- You can also create your own displays.
- DC base accuracy of 0.025%
- AC voltage bandwidth 100 kHz
- True-RMS AC voltage and current for accurate measurements with complex signals or non-linear loads.
- Measure up to 10 A (20 A for up to 30 seconds; 10 A continuously)
- Capacity range 100 mF
- Temperature function
- Relative mode for eliminating the resistance of the test leads when measuring low resistance or capacitance values
- Peak recording for recording transients at speeds up to 250 Ω
- Includes premium test leads and alligator clips
- The optical USB PC communication interface allows for easy sharing of logged data
