Holzstar MDB21 Semi-automatic multi-spindle drilling machine 400V
Special Features
- The machine has 3 operating surfaces: front for pipes (with pipe clamp), top for surface grinding, and rear for cylindrical grinding (with workpiece support)
- Pipe grinder: for pure metal pipes and profiles
- Pipe clamp angle adjustment from 30 to 90°
- Easy clamping and efficient operation with lever handle
- Prism jaw with stop, adjustable without tools
- Powerful motor with 2 speeds for processing both steel and stainless steel
- Quick change of rotation direction and speed with selector switches
- Can be connected to a dust extraction system thanks to the extraction nozzles
- Easy change of the sanding belt and grinding rollers
Advantages
- Drill spindles with six quick-release chucks
- Operation of main functions clamping, drilling, and releasing via foot pedal
- Display of drilling depth and drilling height via counters
- Pneumatic drill head tilting, for drilling in any position between 0° and 90°
Suitable for
- Precisely drilling holes in furniture bodies, frames, or doors
Technical data
- Power kW 1.1
- Voltage V 400
- Motor type S1
- Number of spindles 21
- Spindle spacing mm 32
- Drilling width mm 640
- Speed min-1 2800
- Maximum drilling depth at 90° mm 50
- Workpiece height mm 70
- Spindle distance first to last 640
- Angle adjustment ° 0 - 90
- Work table mm 890x625
- Working pressure bar 6 - 8
- Noise level dB(A) 98.5
- Weight kg 367.00
- Dimensions (lxwxh) mm 3000x1300x1300
Scope of delivery
- 2 pneumatic pressure cylinders
- 6 quick-release drill chucks with a shank diameter of 10 mm
- Sturdy side stop profiles right and left with scale and one each flipstop
- 3-meter backstop with scale and 2 flipstops
- Dutch manual, markings, CE mark, and CE certificate in accordance with Machinery Directive 2006/42/CE and EMC Directive 2014/30/CE
