Leica Rugby CLA-ctive CLX 550 Dual Slope Laser
This laser comes with a 5-year manufacturer's warranty and a unique 2-year Leica knockdown warranty!
The Rugby CLA-CLX550 is a comprehensive digital dual slope laser!
Maximum flexibility and the ability to quickly adapt to work activities are vital for your projects. With the Leica Rugby CLA, you can upgrade your laser and adapt it to the requirements of your application. You pay for the functionality you need to perform your work, and not for extra features you do not use. With additional professional services such as repair and calibration, the exceptional performance of your laser is maintained for many years. With its unique capabilities for adapting to the needs of the specific application through software upgrades, the Leica Rugby CLA is the first upgradable laser for maximum productivity and performance in the field. Thanks to the expansion options, the unparalleled performance can be utilized for all forms of leveling, alignment, and squaring: a true all-rounder.
The Rugby CLA-CLX550 is a comprehensive digital dual-slope laser. The CLA-CLX550 can be set to a percentage slope in two axes via the large illuminated LCD screen on the laser or with the included remote control. This is possible up to a maximum of 8% in the X and Y axes and to three decimal places (00.000%). This allows a very precise slope to be set with the CLA-CLX550, which amounts to an adjustable slope of 1 mm per meter. With the Combo millimeter receiver and remote control, a slope can be entered on the large LCD up to a working range of 300 meters. Naturally, this can also be done easily with automatic alignment, or "slope catching".
Features
- Horizontal & Vertical leveling
- Digital Dual Slope up to 8%
- SCAN Mode (10°, 45° and 90°)
- Adjustable speed (0, 120, 300, 600 and 900 rpm)
- Side shutdown
- Slope catching (automatic alignment)
- Slope lock
- Large illuminated display
- HI Alert (motion warning)
- Temperature warning >50°C
- Temperature stability control (2°C, 5°C or off)
- Battery warning at LOW BATTERY
Technical specifications
- Accuracy ± 10" ± 1.5 mm at 30 m
- Automatic leveling range ± 6°
- Working range with Combo receiver, RE140/160 1350 diameter
- Working range Combo remote control 300 meters
- Manual mode yes
- Water resistance class 100% IP68/MIL-STD-810G
- Operating temperature -20 °C to +50 °C
- Storage temperature -40 °C to +70 °C
- Rotation speed 5, 10, 15 RPS (300, 600 or 900 RPM)
- Hi Alert tilt Shock protection function
- Alarm if Temp. exceeds 50° Celsius
- Batteries Li-Ion 50 hours on 1 charge, 1 hour of charging equals 8 hours of operation
- Battery alarm at 10% battery charge yes
- Rotation speed at low battery charge 7 RPS (low battery)
- Charging time 5 hours
- Weight 3.9 kg
Scope of delivery
- Battery
- Charger
- Case
- Manual
- Calibration report
