Master B300CED Direct-Fired Heater 88kW
Special features B300CED
- To be used exclusively in well-ventilated rooms to prevent oxygen deficiency
- High air volume flow
- Possibility to connect an additional thermostat
- Two diesel filters: diesel tank filter and intake filter
- High-temperature resistant engine
- Electronic flame indicator light with photocell safety device
- Combustion chamber made of stainless steel
- Tank with diesel level indicator
- Easy to move
- Easy maintenance
Technical data
- Net weight (kg) 70
- Dimensions width 750 mm
- Dimensions height 900 mm
- Dimensions length 1600 mm
- Protection IP41
- Fuel consumption 3.5/7 kg/h
- Capacity 2 37,900 - 75,800 kcal/h
- Capacity 3 150,500 - 301,000 BTU/h
- Electrical power supply 220-240/50-60 V/Hz
- Indication current 1.2/2.4 A
- Air volume flow 900/1,800 m³/h
- Tank capacity 105 liters
- Power 44,000 - 88,000 W
Standard included
- In box
- Manual
Comment
