Scangrip 03.5606 Headlamp Ex-view
Special features
- MIDI-EX - Rechargeable, handy EX PROOF work light
- MIDI-EX is a very handy, rechargeable COB LED work light for the professional user
- The COB LED lighting provides unique, powerful, and completely uniform illumination, which is ideal for work lighting
- The extremely durable MIDI-EX lamp has a sturdy surface, and the shape of the lamp ensures a comfortable, ergonomic grip
- Place the lamp wherever you want during inspection work with the rotatable sturdy hook or the strong built-in magnet in the base to keep both hands free for working. The flexible lamp head tilts up to 180 degrees.
- It is designed to be carried in a pocket or on a work belt thanks to the built-in belt clip. This way, you always have the work light at hand when you need to work efficiently and clearly.
- job lighting
- MIDI-EX comes with both a head and a top light. The main lighting offers two-step operation, depending on the type and duration of the work performed: Step 1 = 50%, step 2 = 100% light output
- The design of the MIDI-EX is unique and is covered by EU patent RCD No. 5597010
- II 3G Ex ic IIC T5 Gc
II 3D Ex ic IIIC T100°C Dc - MIDI-EX is approved and certified by TÜV SÜD in accordance with ATEX Directive No. 2014/34/EU effective from April 2016 and in accordance with IECEx
- ATEX Certificate No. TPS 18 ATEX 054006 0015 X Rev.00
IECx Certificate No. IECEx TPS 18.0018X
Technical specifications
- With battery charger: Yes
- Version: Headlamp
- Dimensions: 95mm x 55mm x 43mm
- Material: Metal/plastic
- Battery capacity: 1.6 Ah
- Lamp type: Non-replaceable LED
- Color temperature: 6500 K
- With light source: Yes
- Protection class (IP): IP65
- Energy efficiency class of the built-in lamp: A++, A+, A (LED)
- Light color: Cool white
- Rechargeable: Yes
- Housing color: Black
- Lamp holder: Integrated LED
- Effective luminous flux according to IEC 62722-2-1: 200 lmControl via app: No
- Impact resistance: IK07
- Response brightness: 0 / 300 lx
Scope of delivery
- Lamp
- 1x battery (Lithium ions)
- Charging cable
- Charger
- Certificates
- Manual
