Spit D90 Slotting Saw + AC1625 vacuum cleaner + 2 x diamond saw blades + Dealer warranty!
Spit D90 is the new slotting saw and successor to the D88E for the professional who needs to install both supply and drainage pipes. Now with even more power! In combination with the AC1625, work dust-free at any location.
Features D90
- Extremely suitable for installing electrical, water, and drainage systems.
- Depth adjustment in 2.5 mm increments: from 10 - 50 mm
- Easy operation thanks to ergonomic design
- Width adjustment: from 2.6 to 46.5 mm
- Segment peripheral speed 50 m/s.
- Quick mounting and dismounting of the saw blades thanks to Dia-Quick locking.
- Causes no vibrations: user comfort.
- Saws virtually dust-free in combination with the AC 1625 vacuum cleaner
- Saws up to 20 mm from the ceiling.
- Saws up to 27 mm from an angle.
- Very high sawing speed.
- Features AC1625
- Powerful machine vacuum with automatic cleaning hammer function.
- The vacuum automatically cleans the filters when they become full.
- Suitable for the concrete diamond grinder SG125, dry slotting machine D90, and dry drilling equipment such as the SDM1700.
Technical data D 90
- Arbor hole 22.2mm
- Rotation speed 50m/s
- Power 2500W
- Diamond disc diameter 150mm
- Sawing width 2.6 - 46.5 mm
- Sawing depth 10-50 mm
- Voltage 230V
- Weight 6.5 kg
Technical data AC 1625
- Capacity 25 ltr.
- Power 1600 watts
- Max. suction volume 3840 ltr./min
- Hose length 5 mtr 35 mm
- Weight 11.5 kg
Supplied as standard
- D90 in case
- AC1625
- 2 diamond saw blades (150 mm Uni)
