Trotec 3510205035 BM40 Moisture Meter
Description
Anyone who wants to measure moisture quickly and, above all, non-destructively, or monitor the drying process in materials such as wood or mineral building materials, will find their reliable partner in the BM40.
- To do this, the device's measuring electrodes are simply placed on or near the material to be tested.
- The humidity measurement is performed absolutely non-destructively via capacitive sensors using the dielectric measurement method, as no electrodes or probes need to be inserted into the material to be measured.
- Correction factors for different material types are available for greater accuracy of the measured values, which are given directly in weight percent.
- The The ready-to-use BM40 impresses during measurement with its simple operation and fast response times.
- A measurement of the ambient temperature, the display of the battery status, and the energy-saving auto-off function round off the versatile range of services.
Practical benefits
- Development, design, production: 100% Trotec
- Fast and non-destructive measurement of moisture in mineral building materials and wood
- 10 adjustable material curves for the main building materials and wood types
- incl
- ambient temperature measurement
- Simple operation with just one button
- Direct display of measured value in %
- Battery status indicator
- Automatic shutdown
- Practical-optimized German industrial design - protected design
Technical specifications
- Electrode length: approx. 40 mm
- Measuring principle: dielectric
- Operating environment conditions: -10 to +50 °C / max. 85 %RH
- Storage environment conditions: -10 to +55 °C
- Penetration depth: 0 - 50 mm, non-destructive
- Power supply: 9 V block battery
- Dimensions L x W x H (in mm): 168 x 35 x 75
- Weight: 220g
Solid brick
-
- Measuring range: 0.2 to 15%
- Accuracy: < 2%
- Measuring range: approx. 0.2 to 12%
- Accuracy: < 2%
- Measuring range: 0.1 to 15%
- Accuracy: < 2%
- Measuring range: 0.1 to 20%
- Accuracy: < 2%
- Measuring range: 6 to 23%
- Accuracy: < 2% (with measured value >8%)
- Measurement range: 0.4 to 15%
- Accuracy: < 3%
- Measurement range: 0.1 to 13%
- Accuracy: < 3%
- Measurement range: 1 to 50%
- Accuracy: < 5% (with measured value > 9%)
- Measurement range: 4 to 51%
- Accuracy: < 5% (with measured value > 9%)
- Measurement range: 4 to 50%
- Accuracy: < 5% (with measured value > 9%)
- Wood: 0.1%
- mineral building materials: 0.1%
- Material moisture: 0.5 s
Scope of delivery
- Measuring device
- Battery
- Manual
