Vogt VH 60-130.18 D XL-Set Pneumatic Chipping Hammer Roof Bitumen
Special Features
- If the material is very hard or if the bitumen is tough, it is difficult to remove waterproofing from flat roofs and break open the bonded screed. This takes a toll on the back and muscles. A professional device for flat roof renovation makes sense here. With the VOGT hammer, you can save time and sweat.
- The powerful VH 50.18 or the vibration-dampened VH60.18 have a lot of explosive power and are still easy to handle.
- The length of the device plays an important role: the operator stands upright and can exert significant leverage if necessary. This allows him to break off entire panels after moving the device flat under the material. It is therefore perfect as a bitumen removal device. The extra-strong 18 mm chisel holder ensures that the "crowbar" does not give way. First, a scraper or the cutting carriage cuts through the top seal. The scraper then removes bitumen and thermal insulation. It does not matter whether it is placed in the joint or glued onto profiled sheeting. Nor does it matter whether it concerns cork, HWL, mineral fiber, or polystyrene panels. The flat roof renovation device is suitable for any material. The pneumatic hammer cleanly removes the bottom bitumen layer or the vapor barrier down to the bare concrete and removes nail strips from the wood in a manner gentle on the substrate. For breaking up pitched screeds, or inserting bitumen or decking boards into the mortar bed, the Delta-P blades are the first choice. The tools' powerful explosive action is particularly noticeable with composite screeds and screeds on a separation layer. The bitumen removal device is therefore versatile and operates cleanly and precisely.
Applications
- Freeing bituminous joints
- Loosening caked-on roof gravel
- Removing multi-layer roof membranes
- Scraping off PUR and synthetic resin coatings
- Pre-cutting bitumen membranes up to 25 mm thick
- Breaking up the screed at the bond and at the separation layer
- Repellent floor tiles, leveling compounds, and fillers
- Dismantling bitumen, sheeting, wood, and insulation in the attic
- Scraping off fully bonded bitumen membranes and insulation
Technical data
- Model VH 50-130.18
- Vibration dampened Yes
- Length 130 cm
- Weight 6.7 kg
- Max. Number of strokes 1,960/min
- Operating pressure 3.0 - 6.0 bar
- Air consumption 255 l/min/6 bar
- Cutter holder shank 18 mm
- Sound pressure emission level LPA 94 dB (+3 dB on.) / 6 bar
- Sound power level LWA 105 dB (+3 dB on.) / 6 bar
- Vibration value 4.7 m/s²
- Uncertainty 1.0 m/s²
Scope of delivery
- 1 Delta-P blade M 410.18 UP
- 1 Flat spade GSA 145.18 H
- 1 Scraper holder M 5000.18
- 1 Scraper B 160 S
- 1 Scraper B 200 S
- 1 Adapter 3/4 inch to standard connection Z 200
- 1 Handle Z 650
- 1 Precision line oil gun Z 300
- 1 Deflector Z 910
- 1 Compressed air hose 10 m
- 1 Dirt repellent
- 1 VOGT special oil 0.1 l
- 1 VOGT special oil 1.0 l
- 1 Ring wrench 15/19
- 1 Cutting sled with cutting blade H 425.18 H
- 1 Pair of work gloves
- 1 Safety glasses
- 1 Earplugs
- 1 Metal transport case
- 1 User manual
